Movable Module 25.6/51.2V – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Fri, 30 May 2025 10:29:39 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 LP3000 PRO Series (51.2V 100Ah) https://www.mustpower.com/product/lp3000-pro-series-51-2v-100ah/ Tue, 29 Apr 2025 08:39:17 +0000 https://www.mustpower.com/?post_type=product&p=24986 ⚡ LP3000 PRO Series | High-Performance LFP Battery Modular. Reliable. Smart Storage for Residential & Commercial Solar Systems. The LP3000 PRO Series is a premium lithium iron phosphate (LiFePO₄) battery solution built for solar energy storage and backup power. Designed with advanced BMS, long-lasting LFP chemistry, and a modular plug-and-play structure, it offers unmatched reliability, flexibility, and intelligence—perfect for modern residential and small commercial applications.]]> 🔧 Functions
* Provides 10kW continuous output power and 12kW peak power (30s)
* Modular stackable design—simple plug-and-play installation
* Each module equipped with an independent BMS for better safety and management
* Supports remote firmware upgrades and real-time system monitoring
* Built-in WiFi Smart Module for seamless connectivity
* Compatible with over 15 mainstream inverter brands
* Parallel support for up to 16 units, delivering max capacity of 81.92kWh

💡 Key Selling Points
✅ Up to 7000+ cycles @ 80% DOD, ensuring long service life
✅ IP65-rated enclosure for both indoor and outdoor installation
✅ Cobalt-free LiFePO₄ chemistry for enhanced safety
✅ Supports online diagnostics, upgrades, and O&M
✅ Compact, clean aesthetic with tool-free stacking—ideal for space-limited installations

🏠 Applications
🔋 Residential solar energy storage and self-consumption
💡 Backup power for homes, villas, and small offices
⚙ Small commercial energy storage systems with scalable needs
🌞 Compatible with off-grid, on-grid, or hybrid solar inverter setups

Datesheet LP30-5.1 PRO LP30-10.2 PRO LP30-15.3 PRO LP30-20.4 PRO
Battery Module LP30 PRO-48100
Number of Modules 1 2 3 4
Energy Capacity 5.12kwh 10.24kwh 15.36kwh 20.48kwh
Usable Capacity 4.91kwh 9.83kwh 14.75kwh 19.66kwh
Max. output power 5KW 10KW 10KW 10KW
Dimension (W*D*H)(mm) 595*230*450 595*230*830 595*230*1210 595*230*1590
Weight(kg) 61 110 160 210
* Variations in dimensions and weights may occur due to production batches.
Cycle Life 7000 cycles @ 80% DOD, 25 °C
Maximum Charge Current 100A 150A 200A 200A
Maximum Discharge Current 100A 150A 200A 200A
GENERAL
Battery Type Cobalt Free Lithium Iron Phosphate (LFP)
Nominal Voltage 51.2V
Operating voltage Range 44.8~56.8V
IP Protection IP65
Install location Indoor or outdoor without sunlight exposure
Installation Mode Floor installation, Stackable
Operation Temperature Battery discharge: -20~60°C, battery charge: 0~ 50°C
FEATURES
BMS Monitoring Parameters SOC, System voltage, current, cell voltage, cell temperature, PCBA temperature measurement ,SOH
Communication Port CAN/RS485/BLE/WIFI
Warranty 5years/ 10 years (optional) (25 °C)
CERTIFICATION
EN61000-6-1, EN61000-6-3/ IEC62619/ UN38.3
]]> LP1600 Vertical-mounted (51.2V-300/320Ah) https://www.mustpower.com/product/lp1600-vertical-mounted-51-2v-300-320ah/ Mon, 06 Jan 2025 09:28:42 +0000 https://www.mustpower.com/?post_type=product&p=24878 Vertical-Mounted Version 51.2V | 15.36kWh / 16.38kWh This high-capacity LP1600 model is engineered for vertical floor-standing installation, making it ideal for large-scale residential, commercial, and industrial applications. With up to 40 units in parallel and a robust internal structure, it delivers reliable power in high-demand environments while maintaining safety and energy efficiency. ]]> ✅ Key Features:
Vertical-mounted design for high capacity and stability
Max output power: 7.5KW / 10KW
Built-in Smart BMS with LCD + WiFi remote monitoring
Long lifespan: 6000+ cycles @ 80% DOD, 25°C
Parallel up to 40 units
CAN & RS485 communication ready
Best suited for large villas, off-grid homes, commercial solar storage, and microgrids
High energy density LiFePO₄ cells ensure durability and safety

⚡ Ideal For
• Residential solar ESS
• Commercial backup systems
• Off-grid power stations
• Modular rack systems and hybrid inverter setups

The LP1600 Series brings safety, scalability, and smart control into one powerful energy storage solution — made to evolve with your energy needs.

Technical Data LP16-24100 LP16-24200 LP16-24300 LP16-48100 LP16-48200 LP16-48300 LP16-48320
Nominal Voltage 25.6V 51.2V
Nominal Capacity 100Ah 200Ah 300Ah 100Ah 200Ah 300Ah 320Ah
Nominal energy 2560Wh 5120Wh 7680Wh 5120Wh 10240Wh 15360Wh 16384Wh
Max. output power 2.5KW 3.5KW 5KW 5KW 7.5KW 10KW 7.5KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 29.2V 58.4V
Recommended Charge Current 20A 40A 60A 20A 40A 60A 60A
End Of Discharge Voltage 22V 44V
Standard Method Charge 20A 40A 60A 20A 40A 60A 60A
Discharge 50A 100A 150A 50A 100A 150A 100A
Maximum Continuous Current Charge 100A 150A 200A 100A 150A 200A 150A
Discharge 100A 150A 200A 100A 150A 200A 150A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V (2s) (2.75V/Cell) 44.0V (2.75V/Cell)
Temperature Charge 0~50°C
Discharge -20~60°C
Storage Temperature -5~35°C
Shipment Voltage ≥25.6V ≥51.2V
Safety Function Over-charge, Over-discharge, Over-current, Low/High-temperature, Short-circuit Protections
Module Parallel Up to 40 units
Communication CAN2.0/RS232/RS485
IP Protection level IP21
Case Material SPCC
Installation Mode Wall-mounted, Stacked-mounted, Rack-mounted(optional) Vertical-mounted
Machine Dimension (W*H*D) (mm) 442*485.5*177 442*486.5*250 442*495*230 442*625.5*177 442*686.5*250 490*923*265
Package Dimension (W*H*D) (mm) carton box 557*227*547 557*300*547 / 688*227*557 non /
wooden box 555*340*565 555*410*565 600*570*405 700*570*350 759*405*569 1000*450*565
N.W (kg) 27 44 68 45 80 117
G.W (kg) carton box 30 48 / 48 non /
wooden box 40 57 85 58 97 137
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) IEC62619-1:2018; IEC62619:2022; IEC62619:2017; UN38.3/ MSDS
]]> LP3000 Series (51.2V-100Ah) https://www.mustpower.com/product/lp3000-series-51-2v-100ah/ Tue, 23 Apr 2024 10:44:09 +0000 https://www.mustpower.com/?post_type=product&p=24131 Lithium Iron Phosphate (LiFePO4) Battery 5.12~40.96KWH | WiFi | IP65 The LP3000 series is an advanced lithium iron phosphate (LFP) battery designed for solar energy storage and backup power applications. With its safe, long-lasting LFP chemistry, intelligent battery management system, and robust design, this battery provides an ideal storage solution for residential and commercial renewable energy systems.]]> ■ Max Continuous power 10kw
■ Standard warranty: 10 years
■ Peak power 12kw@30S
■ Easy installation with modular and stacked design, just plug and play
■ Real-time monitoring of battery charging and discharging, online system updates and maintenance
■ IP65 protection level design Suitable for indoor and outdoor
■ Excellent safety of cobalt free LiFePO4 battery
■ Latest LFP technology: >7000 cycles @ 80% DOD, 25 °C
■ Remote firmware upgrade
■ Independent BMS system for each module
■ Compatible with most popular inverter models (more than 15) on the market.
■ Stack up to 8 batteries(8*5.12kwh), parallel up to 16 batteries (max capacity: 81.92kWh)
■ Built-in WiFi Smart Module

Datesheet LP30-5.1 LP30-10.2 LP30-15.3 LP30-20.4 LP30-25.5 LP30-30.6 LP30-35.7 LP30-40.8
Battery Module LP30-48100
Number of Modules 1 2 3 4 5 6 7 8
Energy Capacity 5.12kwh 10.24kwh 15.36kwh 20.48kwh 25.6kwh 30.72kwh 35.84kwh 40.96kwh
Usable Capacity 4.91kwh 9.83kwh 14.75kwh 19.66kwh 24.58kwh 29.49kwh 34.41kwh 39.32kwh
Max. output power 5KW 10KW 10KW 10KW 10KW 10KW 10KW 10KW
Dimension (W*D*H)(mm) 620*360*360 620*360*570 620*360*780 620*360*1090 620*360*1200 620*360*1410 620*360*1620 620*360*1830
Weight(kg) 62 112 162 212 262 312 362 412
* Variations in dimensions and weights may occur due to production batches.
Cycle Life 7000 cycles @ 80% DOD, 25 °C
Maximum Charge Current 50A 75A 100A 125A 150A 175A 200A 200A
Maximum Discharge Current 100A 200A 200A 200A 200A 200A 200A 200A
GENERAL
Battery Type Cobalt Free Lithium Iron Phosphate (LFP)
Nominal Voltage 51.2V
Operating voltage Range 44.8~56.8V
IP Protection IP65
Install location Indoor or outdoor without sunlight exposure
Installation Mode Floor installation, Stackable
Operation Temperature Battery discharge: -10~55°C, battery charge: 0~45°C
FEATURES
BMS Monitoring Parameters SOC, System voltage, current, cell voltage, cell temperature, PCBA temperature measurement ,SOH
Communication Port CAN/RS485/BLE/WIFI
Warranty 10 years (standard warranty) (25 °C)
CERTIFICATION
CE/ IEC62619 / UL1973 / UL9540A / UN38.3
]]> LP2100 Series (51.2V-280/300/314Ah) https://www.mustpower.com/product/lp2100-series-51-2v-280-300-314ah/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23936 LiFePO4 Battery 14336Wh/15360Wh/16076Wh LP2100 Series is a lithium battery specially designed for residential applications with superior performance. Compatible with MUST PV/ EP/PH inverters series, one-stop-shop solution can be designed with LP2100 series, save you precious time and money, ideal solution for large home and small commercial with strong capacity 14.3kWh/15.3kWh/16kWh.]]>

Technical Data LP21-48280 LP21-48300 LP21-48314
Nominal Voltage 51.2V
Nominal Capacity 280Ah 300Ah 314Ah
Nominal energy 14336Wh 15360Wh 16076Wh
Max. output power 10KW 10KW 10KW
Life Cycles 6000 cycles @ 80% DOD, 25℃
Recommended Charge Voltage 57.6V
Recommended Charge Current 56A 60A 60A
End Of Discharge Voltage 44V
Standard Charge Current 56A 60A 60A
Standard Discharge Current 140A 150A 150A
Maximum Continuous Charge Current 200A 200A 150A
Maximum Continuous Discharge Currentt 200A 200A 150A
BMS Cut-Off Voltage Charge 58.4 V (3.65V/Cell)
BMS Cut-Off Voltage Discharge 44.0V (2s) (2.75V/Cell)
Temperature Charge 0~45°C
Temperature Discharge -10~55°C
Storage Temperature -5~35°C
Shipment voltage ≥51.2V
Module Parallel Up to 15 units
Communication CAN2.0/RS232/RS485
Case Material SPCC
Machine Dimension (W*H*D) (mm) 260*733*633
Package Dimension (W*H*D) (mm) wooden box 440*870*720 / /
N.W (kg) 118 / /
G.W (kg) wooden box 138 / /
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge
retention rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) UN38.3/ MSDS / IEC62619:2017
]]> LP2000 Series (25.6V-200/280Ah) https://www.mustpower.com/product/lp2000-series-25-6v-200-280ah/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23875 LiFePO4 Battery 5120Wh 7168Wh 10240Wh 14336Wh LP2000 is a new type of lithium battery energy storage system. Energy storage is configured differently depending on the needs of the home, the battery capacity is 5.12kWh to 14.3kWh. Very suitable for home emergency power storage as solar battery.]]> ■ 6000 cycles @ 80% DOD, 25°C
■ Built-in WiFi Smart BMS Module
■ Modular design: supports up to 15 units in parallel
■ Spinner wheels design
■ IP21 protection for both indoor use
■ Support CAN & RS485 communication with mainstream inverters

Technical Data LP20-24200 LP20-24280 LP20-48200 LP20-48280
Nominal Voltage 25.6V 51.2V
Nominal Capacity 200Ah 280Ah 200Ah 280Ah
Nominal energy 5120Wh 7168Wh 10240Wh 14336Wh
Max. output power 3.5KW 5KW 7.5KW 10KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 57.6V
Recommended Charge Current 40A 56A 40A 56A
End Of Discharge Voltage 44V
Standard Method Charge 40A 56A 40A 56A
Discharge 100A 140A 100A 140A
Maximum Continuous Current Charge 150A 200A 150A 200A
Discharge 150A 200A 150A 200A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V (2.75V/Cell) 44.0V (2.75V/Cell)
Temperature Charge 0~45°C
Discharge -10~55°C
Storage Temperature -5~35°C
Shipment voltage ≥25.6V ≥51.2V
Module Parallel Up to 15 units
Communication CAN2.0/RS232/RS485
Case Material SPCC
Machine Dimension (W*H*D) (mm) 540*430*533 540*429*533 540*430*533 540*547*533
Package Dimension (W*H*D) (mm) wooden box 624*624*567 624*624*567 624*624*567 644*604*674
N.W (kg) 54 86 86 115
G.W (kg) wooden box 70 102 103 135
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) UN38.3/ MSDS
]]> LP2000 Series (51.2V-200/280Ah) https://www.mustpower.com/product/lp2000-series-51-2v-200-280ah/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23876 LiFePO4 Battery 5120Wh 7168Wh 10240Wh 14336Wh LP2000 is a new type of lithium battery energy storage system. Energy storage is configured differently depending on the needs of the home, the battery capacity is 5.12kWh to 14.3kWh. Very suitable for home emergency power storage as solar battery.]]> ■ 6000 cycles @ 80% DOD, 25°C
■ Built-in WiFi Smart BMS Module
■ Modular design: supports up to 15 units in parallel
■ Spinner wheels design
■ IP21 protection for both indoor use
■ Support CAN & RS485 communication with mainstream inverters

Technical Data LP20-24200 LP20-24280 LP20-48200 LP20-48280
Nominal Voltage 25.6V 51.2V
Nominal Capacity 200Ah 280Ah 200Ah 280Ah
Nominal energy 5120Wh 7168Wh 10240Wh 14336Wh
Max. output power 3.5KW 5KW 7.5KW 10KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 57.6V
Recommended Charge Current 40A 56A 40A 56A
End Of Discharge Voltage 44V
Standard Method Charge 40A 56A 40A 56A
Discharge 100A 140A 100A 140A
Maximum Continuous Current Charge 150A 200A 150A 200A
Discharge 150A 200A 150A 200A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V (2.75V/Cell) 44.0V (2.75V/Cell)
Temperature Charge 0~45°C
Discharge -10~55°C
Storage Temperature -5~35°C
Shipment voltage ≥25.6V ≥51.2V
Module Parallel Up to 15 units
Communication CAN2.0/RS232/RS485
Case Material SPCC
Machine Dimension (W*H*D) (mm) 540*430*533 540*429*533 540*430*533 540*547*533
Package Dimension (W*H*D) (mm) wooden box 624*624*567 624*624*567 624*624*567 644*604*674
N.W (kg) 54 86 86 115
G.W (kg) wooden box 70 102 103 135
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) UN38.3/ MSDS
]]> LP1600 Stacked-mounted (25.6/51.2V-100/200/300Ah) https://www.mustpower.com/product/lp1600-wall-mounted-25-6-51-2v-100-200-300ah-3/ Wed, 06 Mar 2024 11:29:35 +0000 https://www.mustpower.com/?post_type=product&p=23862 Stacked-Mounted Version 25.6V & 51.2V | 2.56kWh ~ 10.24kWh Flexible, compact, and installation-friendly — this LP1600 variant is designed with three adaptable mounting options: wall-mounted, stacked-mounted (up to 5 units), or rack-mounted. Perfect for homes, telecom setups, and light commercial energy storage, it allows users to optimize space without compromising on performance. ]]> 🔧 Voltage & Capacity Options:
25.6V: 100Ah / 200Ah / 300Ah → 2.56 / 5.12 / 7.68 kWh
51.2V: 100Ah / 200Ah → 5.12 / 10.24 kWh

✅ Key Features:
All-in-one 3-in-1 design: Wall-mounted, Stacked, or Rack-mounted
Modular: Up to 40 units in parallel
Max output power: 2.5KW to 5KW
Smart WiFi BMS with LCD display
Long lifespan: 6000+ cycles @ 80% DOD, 25°C
CAN & RS485 communication compatibility
Sleek and durable casing for modern energy setups
Ideal for residential solar systems, mobile stations, backup energy needs

⚡ Ideal For
• Residential solar ESS
• Commercial backup systems
• Off-grid power stations
• Modular rack systems and hybrid inverter setups
The LP1600 Series brings safety, scalability, and smart control into one powerful energy storage solution — made to evolve with your energy needs.

Technical Data LP16-24100 LP16-24200 LP16-24300 LP16-48100 LP16-48200 LP16-48300 LP16-48320
Nominal Voltage 25.6V 51.2V
Nominal Capacity 100Ah 200Ah 300Ah 100Ah 200Ah 300Ah 320Ah
Nominal energy 2560Wh 5120Wh 7680Wh 5120Wh 10240Wh 15360Wh 16384Wh
Max. output power 2.5KW 3.5KW 5KW 5KW 7.5KW 10KW 7.5KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 29.2V 58.4V
Recommended Charge Current 20A 40A 60A 20A 40A 60A 60A
End Of Discharge Voltage 22V 44V
Standard Method Charge 20A 40A 60A 20A 40A 60A 60A
Discharge 50A 100A 150A 50A 100A 150A 100A
Maximum Continuous Current Charge 100A 150A 200A 100A 150A 200A 150A
Discharge 100A 150A 200A 100A 150A 200A 150A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V (2s) (2.75V/Cell) 44.0V (2.75V/Cell)
Temperature Charge 0~50°C
Discharge -20~60°C
Storage Temperature -5~35°C
Shipment Voltage ≥25.6V ≥51.2V
Safety Function Over-charge, Over-discharge, Over-current, Low/High-temperature, Short-circuit Protections
Module Parallel Up to 40 units
Communication CAN2.0/RS232/RS485
IP Protection level IP21
Case Material SPCC
Installation Mode Wall-mounted, Stacked-mounted, Rack-mounted(optional) Vertical-mounted
Machine Dimension (W*H*D) (mm) 442*485.5*177 442*486.5*250 442*495*230 442*625.5*177 442*686.5*250 490*923*265
Package Dimension (W*H*D) (mm) carton box 557*227*547 557*300*547 / 688*227*557 non /
wooden box 555*340*565 555*410*565 600*570*405 700*570*350 759*405*569 1000*450*565
N.W (kg) 27 44 68 45 80 117
G.W (kg) carton box 30 48 / 48 non /
wooden box 40 57 85 58 97 137
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) IEC62619-1:2018; IEC62619:2022; IEC62619:2017; UN38.3/ MSDS
]]>
