European Products – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Wed, 25 Jun 2025 08:39:00 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 HBP1100 PRO Series (3.6-6KW) https://www.mustpower.com/product/hbp1100-pro-series-3-6-6kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23948 Renewable Energy Storage 3.6~6KW | 5120Wh/10240Wh/15360Wh | PV 500V HBP1100 PRO energy storage system is an all-in-one solution, which integrated a hybrid solar inverter & lithium battery in to one unit. This model combines functions both off grid and on grid which could manage your solar home battery storage easily. Flexible modular system could be designed based on house dailyconsumption. ESS is easily to select the priority of power supply, it allows you to store the energy to self-consumption and sell to the grid. ESS is the best emergency energy solution for villas, apartments,hotels,shopping centers.]]> ■ Lithium Battery Modular 5120Wh/10240Wh/15360Wh
■ Self-consumption and feed-back to the grid
■ Multiple Working Mode: Energy storage mode, load priority mode, power selling mode,and a high-efficiency mode (six time periods are provided for setting different modes to achieve peak-shaving and valley-filling, maximizing economic benefits)
■ Inside BMS,support to be charged and discharged according to bms requirements
■ Support to connect with generator
■ Automatic line-to-battery switch over

MODEL HBP11-3648 PRO HBP11-4048 PRO HBP11-4648 PRO HBP11-5048 PRO HBP11-6048 PRO
Rated power 3600W 4000W 4600W 5000W 6000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4000W 5000W 5500W 6000W 7000W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER OUTPUT(AC)
Nominal AC output power 3600W 4000W 4600W 5000W 6000W
Nominal output voltage; range 220/230/240V;180-280V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal output current 15.6A 17.5A 20A 21.7A 26A
Maximum output current 16A 18.1A 20.8A 22.7A 27.2A
Inrush current (spike/duration) 57.5A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading~0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W 4600W 5000W 6000W
Nominal output voltage; accuracy range 230±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 15.6A 17.5A 20A 21.7A 26A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s 6900W,10s 7500W,10s 9000W,10s
Total harmonic distortion (linear load) <3%
BATTERY & CHARGER
Note: Below Parameters base on one LiFePO4 Lithium Battery Modular
Battery parameter 51.2VDC 100Ah
Number of battery pack 1 2 1 2 2 3 2 3 2 3
Capacity 5120Wh 10240Wh 5120Wh 10240Wh 10240Wh 15360Wh 10240Wh 15360Wh 10240Wh 15360Wh
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W 4600W 5000W 6000W
Maximum charging currernt 75A 85A 95A 100A 125A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) (Inverter+Battery) 594*1154*220(5120Wh); 594*1559*220 (10240Wh); 594*1964*220 (15360Wh)
Package Dimension (W*H*D)(mm) Inverter 900*335*714
Battery 666*280*483 (Single Battery)
N.W(kg) Inverter 42
Battery(51.2V100Ah) 52
G.W(kg) Inverter 55
Battery(51.2V100Ah) 57
Standard Warranty Inverter: 5 years ; Lithium battery: 5 years
OTHER
Operating Temperature Range -15°C to 40°C
Ingress protection rating IP66
Audible Noise 60dB MAX
Display LED+LCD
CERTIFICATION & STANDARDS
CE-EMC
]]> Balcony Solar System PM Series + HPC Series https://www.mustpower.com/product/balcony-solar-system-pm-series-hpc-series/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23949 Balcony Power Plant with Storage Discover the perfect energy solution tailored for diverse living spaces. Whether you reside in an apartment with a sun-kissed balcony or own a detached home boasting a lush garden, the HPC+PM series is designed to fit seamlessly. Even if you're looking to harness solar power from a detached house balcony or rooftop, our product ensures optimal performance. Embrace a sustainable future, no matter where you live, and let the HPC+PM series illuminate every corner of your home.]]> MICRO INVERTER PM Series

The PM Series Microinverter is the ideal micro-inverter for balcony power plants, converting PV power from balcony power plants or roof installations in line with grid requirements and feeds it directly into the domestic grid, where it is immediately used.
With the output power up to 2000 VA, MUST new microinverter PM series rank among the higher for 2-in-1 microinverters.
Each microinverter can connect up to 2 panels, with independent MPPT and monitoring maximizing the power production of your installation.

■ Plug-and-Play Made Effortless
■ Single unit connects to 4 PV panel
■ Maximum continuous Ac output power 2000VA
■ IP67 protection degree
■ Dual MPPT for maximum power generation and efficiency
■ WIFI remote monitoring
■ Multiple protection functions
■ Suitable for crystalline silicon and thin film PV panel

No single point of failure. If a system with a central inverter fails, solar production will stop completely. With one microinverter per module, solar production keeps working even if a microinverter fails.

Model PM-800 PM-1000 PM-1600 PM-2000
INPUT(DC)
Recommended solar panel input power(W) 275-530W× 2 275-530W× 2 275-530W× 4 275-530W× 4
Number of DC input connections (group) MC4 × 2 MC4 × 4
Maximum DC input voltage 60V 60V
Operating voltage range 16-60V 16-60V
Start-up voltage 22V 22V
MPPT tracking range 22-55V 22-55V
MPPT tracking accuracy >99.5% >99.5%
Maximum DC input current 14A*2 16A*2 14A*4 16A*4
OUTPUT(AC)
Max. continuous output power 800W 1000W 1600W 2000W
Nominal output voltage 230V 230V 230V 230V
Operating voltage range 190-270V 190-270V 190-270V 190-270V
Max. continuous output current 3.47A 4.34A 6.95A 8.69A
Nominal output frequency 50Hz/60Hz
Output frequency range 47.5-50.5Hz/58.9-61.9Hz
Maximum units per branch 6set 6set 2set 2set
THD <5%
Power factor >0.99
Peak efficiency 96%
Protective class Class I
PROTECTION FUNCTION
Over/under voltage protection yes
Over/under frequency protection yes
Anti-islanding protection yes
Over current protection yes
Over load protection yes
Over temperature protection yes
Protection grade IP67
Working environment temperature -40℃ ~ +65℃
Indication light quantity Working status: Led light + Wi-Fi Signal Led light
Communication  connection mode Wifi/2.4G
Cooling method Natural cooling(no fan)
Working environment Indoor / outdoor
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 227*195.5*42 342*225.4*50
Package Dimension (W*H*D)(mm) / /
N.W(kg) 2.52 5.2
G.W(kg) / /
Standard Warranty 10 years
CERTIFICATION & STANDARDS
VDE: VDE-AR-N 4105    CE-LVD: EN62109-1, EN62109-2    Rohs: IEC62321

BALCONY SOLAR ENERGY STORAGE BATTERIES HPC1800 Series

The HPC1800 is designed for balcony energy storage systems. Compatible with MUST PM series microinverters and built-in MPPT solar charge controller, the energy storage battery provides power to the microinverter during daytime hours or night hours, which saves the family’s electricity bill and promotes the use of clean energy. Users can choose the battery pack according to their own energy storage needs, with battery capacity from 1280Wh to 2500Wh.

■ Plug in and Play
■ Easy to Install & Move
■ Space-Saving efficient Use of Space
■ Dual MPPT 800W PV input economical Solutions for Savings
■ IP65 Waterproof & Dustproof, adaptable for Various Use Cases
■ 6000 Cycles LiFePO4 Batterywith 10 Years Lifespan
■ Low noise fanless design
■ Compatible with 99% of solar panels and microinverters on the market

Model HPC1800
GENERAL
Capacity 2330Wh
Material of cell LiFePO4
Cycles >6000@80%Capacity
Storage Temperature -20°C~50°C
Operating Temperature -10°C~45°C
Battery Management System(BMS) OVP, UVP, OCP, SCP, OTP, UTP, etc
PHOTOVOLTAIC INPUT
Power 2*500W max
Range of input voltage 15V~70V
Max input current 2*10A
BATTERY OUTPUT
Power 2*400W max
Range of output voltage 42V~50.4V
Max output current 11.9A
BATTERY
Nominal voltage 44.8V
Charging voltage 50.4V
Max charging current 50A (1C)
Max discharge current 50A (1C)
Depth of discharge 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 390*200*395
Package Dimension (W*H*D)(mm) 490*300*490
N.W (kg) 25
G.W (kg) 28
Standard Warranty 5years
CERTIFICATION & STANDARDS
VDE: VDE-AR-N 4105 CE-LVD: EN62109-1, EN62109-2
]]> PH1600 PRO Series (4-6KW) https://www.mustpower.com/product/ph1600-pro-series-4-6kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23952 AC Coupled Energy Storage Inverter 4~6KW | Single Phase | 230VAC The PH1600 PRO Series is designed for retrofitting PV systems, including power classes ranging from 4kw to 6kw. It can be installed with existing PV inverters, forming an AC coupling system. Capable of being grid-interactive, it allows users to store surplus power and sell it back to the grid when demand peaks and the price of electricity is at its highest. It runs reliably under even the most extreme conditions with metal aluminium housing with IP66 protection.]]> ■ LCD+LED – user friendly interface

■ IP66 design for outdoor

■ Compatible with other brands of inverter

■ Various work mode for different application scenarios

■ Natural cooling without external fan

■ BMS Function

■ Wifi monitoring

■ UPS level switching time <10 ms ■ Retrofit any on-grid systems to be able to run battery

MODEL PH16-4048 PRO PH16-5048 PRO PH16-6048 PRO
Rated AC output power 4000W 5000W 6000W
Nominal Battery System Voltage 48V
INVERTER OUTPUT(AC)
Nominal AC output power 4000W 5000W 6000W
Nominal output voltage range 220/230/240V;180-280V ±5VAC
AC grid frequency range 50/60Hz; 45~55/55-65Hz
Nominal output current 17.5A 21.7A 26A
Maximum output current 18.1A 22.7A 27.2A
Inrush current (spike/duration) 57.5A/5.2us
Total harmonic distortion i(THDi) @Nominal Output <3%
Power factor at rated power ≈1
Displacement power factor Adjustable from 0. 8 leading to 0. 8 lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 4000W 5000W 6000W
Nominal output voltage; accuracy range 230±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 17.5A 23A 26A
Output waveform Pure sine wave
Peak power 6000W/10S 7500W/10S 9000W/10S
Total harmonic distortion v (linear load) <3%
BATTERY & CHARGER
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V ±0.3
Battery voltage range 40~60V ±0.3
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 4000W 5000W 6000W
Maximum charging currernt 85A 105A 125A
EFFICIENCY
Battery discharge (full load) 94.5%
Maximum battery charging current efficiency 94.5%
PROTECTION DEVICES
Grid monitoring Yes
Output over current protection Yes
Output overvoltage protection-varistor Yes
Ground fault monitoring Yes
Integrated all-pole sensitive leakage current Yes
GENERAL
Machine Dimension (W*H*D)(mm) 410*420*215
Package Dimension (W*H*D)(mm) /
N.W(kg) 25
G.W(kg) /
AC connection Terminal Block
Display LED+LCD
Communication interfaces Wi-Fi/USB/GPRS/RS485/CAN
Ingress protection rating IP66
Humidity 0~95% RH(No codensing)
Operating temperature range -20°C+60°C With derating above 45°C
Cooling concept Natural
Noise figure [dB] ≤25
Altitude <3000m
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN IEC61000-6-3: 2007, ENIEC61000-6-1:2017; EN IEC62477-1:2022)
]]> ECO181 Series (1/1.5KW) https://www.mustpower.com/product/eco181-series-1-1-5kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23935 Portable Power Station 1~1.5KW | 24V,48V | 110V,230V MUST portable power stations are battery-powered generators that keep your gear charged up and ready wherever you are. From family camping to home backup, get yourself convenient power without the noise, fumes, and fuss of a traditional gas generator.]]> ■ Portable and easy carry
■ Huge AC output
■ Seamless 24/7 UPS, Plug and play home backup power
■ Multiple Charging Ways Available: AC Charging, Solar Charging, Car Charging

MODEL EM1024S EM1548S
Nominal Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated power 1000W 1500W
Output voltage waveform Pure Sine Wave
Output voltage regulation 110V±5%; 230V±5%
Output frequency 50Hz / 60Hz (±0.2Hz)
Peak efficiency 2000W (max) 3000W (max)
Standby Consumption 110V< 12W; 220V< 25W
PV INPUT
Max solar power input 600W 1000W
PV max charging current 25A 20A
Max efficiency 95.0% (max)
PV array open circuit voltage 60V (max) 80V (max)
PV Array MPPT Voltage Range 12~60V 12~80V
AC INPUT
AC input voltage 110VAC ±5%; 230VAC ±5%
Acceptable input voltage range 90-130VAC; 180-260VAC
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time ≤15ms
AC CHARGE
Charging current @ Nominal input voltage 600W@110V; 600W@220V 1000W@110V; 1000W@220V
Charging Algorithm Equalize charge – Trickle charge
OUTPUT
AC output 110Vac (Socket *3pcs); 230Vac (Socket *2pcs)
Car charger output (cigarette lighter) 120W
DC output (DC5521) 60W*2
USB-C(Type-C) PD18W*1+PD60W*2
USB-A(USB) QC18W*3
LED (white light) 2W
LITHIUM BATTERY
Energy 1280Wh 1433Wh
Nominal voltage 25.6V 51.2V
Battery capacity 50Ah 28Ah
Protection board 100A 80A
Standard charging & discharge current Charging@25A; discharge@50A Charging@20A; discharge@40A
Operation temperature -10°C to 45°C -10°C to 45°C
Storage temperature -10°C to 55°C -10°C to 55°C
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 440*233.2*263.3
Package Dimension (W*H*D)(mm) 504*314.5*345
N.W(kg) 17.9 19.5
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN55032+A11, EN55035+A11, EN61000-3-2+A1, EN61000-3-3+A1, EN IEC62368-1+A11) Rohs2.0(2011/65/EU)(2015/863/EU)
]]> Micro Inverter PM Series (IP67 600-2000W) https://www.mustpower.com/product/micro-inverter-pm-series-ip67-600-2000w/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23941
  • Inverter 600/800/1600/2000W IP67 waterproof
  • Aluminum alloy body in high pressure oxidation process with good corrosion and oxidation resistance. The micro inverter waterproof according to IP67 to prevent rain drops from entering.
  • Ultimate craftsmanship and comfortable installation design
  • Inverter balcony power station is plug and play, so it can be installed without professional training or electrician. Connect the solar model to the MC-4 cable with two branch outputs.
  • Intelligent Online Monitoring
  • PV inverter has MPPT function, intelligent WiFi module and is equipped with a new generation of smart home WiFi monitoring system that can achieve intelligent online surveillance.
    • Model PM-600 PM-800 PM-1600 PM-2000
    Input Data(DC)
    Recommended solar panel input power 200-430W × 2 275-530W× 2 275-530W× 4 275-530W× 4
    Number of DC input connections MC4 × 2 MC4 × 4
    Max. input voltage 60V 60V
    PV Operating voltage 16-60V 16-60V
    Start-up voltage 22V 22V
    MPPT tracking range 22-55V 22-55V
    MPPT tracking accuracy >99.5% >99.5%
    Max. continuous input current 10A*2 14A*2 14A*4 17A*4
    Output Data(AC)
    Max. continuous output power 600W 800W 1600W 2000W
    Nominal output voltage 230V 230V 230V 230V
    Operating voltage range 190-270V 190-270V 190-270V 190-270V
    Max. continuous output current 2.6A 3.47A 6.95A 8.69A
    Nominal output frequency 50Hz/60Hz
    Output frequency range 47.5-50.5Hz/58.9-61.9Hz
    Maximum units per branch 8set 6set 2set 2set
    THD <5%
    Power factor >0.99
    Peak efficiency 96%
    Protective class Class I
    Protection Function
    Over/under voltage protection Yes
    Over/under frequency protection Yes
    Anti-islanding protection Yes
    Over current protection Yes
    Over load protection Yes
    Over temperature protection Yes
    Type of enclosure IP67
    Operating ambient temp. -40℃ to +65℃
    Indication light quantity Working status: Led light + Wi-Fi Signal Led light
    Communication connection mode Wi-Fi / 2.4G
    Cooling method Natural cooling(no fan)
    Working environment Indoor and Outdoor
    Weight 2.5Kg 4.5Kg
    Size (L*W*H)mm 315*226*45 342*205*45
    Standards VDE：VDE-AR-N 4105

    CE-LVD：EN62109-1, EN62109-2

    Rohs：IEC62321

    ]]>         PH1100 EU Series (AC:380V 5-12KW) https://www.mustpower.com/product/ph1100-eu-series-ac380v-5-12kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23943 ON/OFF GRID HYBRID SOLAR INVERTER 5~12KW | Three Phase | 380VAC PH1100 EU is brand new three phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and high-power density, this series supports 1.3 DC/AC ratio, saving device investment. It supports three phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.]]> ■ 100% unbalanced output, each phase max. output up to 50% rated power
    ■ Max. 6 pcs parallel for on-grid and off-grid operation
    ■ AC couple to retrofit existing solar system
    ■ Support multiple batteries parallel
    ■ Max. charging/discharging current of 240A
    ■ Support storing energy from diesel generator
    ■ 48V low voltage battery, transformer isolation design
    ■ IP66 water-proof and dust-proof
    ■ “Time of use” function: a maximum of 6 time segments can be set
    ■ Wifi monitoring

    MODEL PH11-5KL3-EU PH11-6.5KL3-EU PH11-8KL3-EU PH11-10KL3-EU PH11-12KL3-EU
    Rated power 5000W 6500W 8000W 10000W 12000W
    BATTERY INPUT DATA
    Battery type Lead-acid battery / Lithium battery
    Battery voltage 48V
    Battery voltage range 40~60V
    Charging curve 3-stage adaptive with maintenance/Equalization
    Charging Strategy for Li-lon Battery Self-adaption to BMS
    Over-current protection/ Over-temperature protection Yes / Yes
    Maximum charging/discharging power 5000W 6500W 8000W 10000W 12000W
    Maximum charging/discharging current 120A 150A 190A 210A 240A
    PV STRING INPUT DATA
    Max. DC Input Power 6500W 8450W 10400W 13000W 15600W
    Rated PV Input Voltage 550V
    Maximum DC voltage 800V
    Start-up Voltage 160V
    Minimum voltage for grid connection 310V
    Full Load DC Voltage Range 350-650V
    Enter high voltage error recovery point 800V
    MPPT voltage range 200~650V
    Maximum input current 13A/13A 13A+26A
    No.of MPP Trackers 2
    No.of Strings per MPP Tracker 1+1 2+1
    AC INPUT/OUTPUT DATA
    Rated AC Input/ Output Power 5000W 6500W 8000W 10000W 12000W
    Max AC Input/ Output Power 5500W 7150W 8800W 11000W 13200W
    AC Input/ Output Rated Current 7.6/7.2A 9.8/9.42A 12.1/11.6A 15.2/14.5A 18.2/17.4A
    Max AC Input/ Output Current 8.4/8A 10.8/10.4A 13.4/12.8A 16.7/15.9A 20/19.1A
    Max. Three-phase Unbalanced Output Current 11.4/10.9A 14.7/14.1A 18.2/17.4A 22.7/21.7A 27.3/26.1A
    Power Factor Adjustment Range 0.8 leading to 0.8 lagging
    Rated Input/Output Voltage 220/380,230/400Vac
    Rated Input/Output Grid Frequency/Range 50/60;45~55/55-65
    Grid Type Three Phase
    Total Harmonics Current Distortion (THDi) <3% (of nominal power)
    DC Current Injection <0.5% In
    EFFICIENCY
    Max. Efficiency ≥97.6%
    Euro Efficiency 97.0%
    PROTECTION
    Integrated Islanding protection, PV input polarity reverse protection, insulationresistance detection, surge protection,leakage current monitoringprotection,output current protection, output short circuit protectionoutput overvoltage protection
    Surge Protection DC Type III/AC Type III
    Overvoltage Category DC Type II/AC Type III
    GENERAL DATA
    Operating Temperature Range (°C) -25°C to +60°C, >45°C Derating
    Cooling Fan cooling
    Noise (dB) ≤55dB
    Communication with BMS RS485/CAN
    Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
    Package Dimension (W*H*D)(mm) 567*816*404
    N.W(kg) 38
    G.W(kg) 42
    Protection Degree IP66
    Installation Style Wall-mounted
    Warranty 5 Years
    the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
    CERTIFICATION & STANDARDS
    CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC 62109-1, EN IEC 62109-2); CE-LVD(EN 62477-1) ; IEC 60529; EN50549-1; Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021)C10/C11; UNE217001-2020; UNE217002-2020, NTS-631 (Type A); G98+G99
    ]]>         PH5900 TM Series (17-25KW) https://www.mustpower.com/product/ph5900-tm-series-17-25kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23944 High Frequency On Grid Solar Inverter 17~25KW | Three-phase | MPPT 200V-1000V PH5900TM series PV inverters take full account of the needs of end customers, It is used to convert the DC generated by photovoltaic panels into AC and send it to the grid in a three-phase manner.with excellent performance at the same time, use LED as inverter status display, effectively improve product life. Using DSP digital control,could afford wide grid voltage range, have a full range of protection features; to maximize the benefits at the same time, greatly enhance the reliability of the product.]]> ■ Wide MPPT voltage range from 200V-1000V

    ■ IP66 protection degree

    ■ Integrated DC switch

    ■ DSP controller

    ■ The maximum efficiency is 98.6%

    ■ Multi MPPT controller

    ■ WIFI monitoring standard

    ■ Easy installation

    MODEL PH59-17000 TM PH59-18000 TM PH59-19000 TM PH59-20000 TM PH59-21000 TM PH59-22000 TM PH59-23000 TM PH59-24000 TM PH59-25000 TM
    Rated AC output power 17000W 18000W 19000W 20000W 21000W 22000W 23000W 24000W 25000W
    OUTPUT (AC)
    Max.AC apparent power 18700VA 19800VA 20900VA 22000VA 23100VA 24200VA 25300VA 26400VA 27500VA
    Max.output current 27.1A 28.6 30.2 31.8A 33.5A 35A 36.6A 38A 39A
    Nominal AC Voltage 230V/400V
    AC Voltage range 320-478V
    AC grid frequency range 50/60±5Hz
    Power factor at Rated power 1
    Adjustable displacement power factor 0.8leading. 0.8lagging
    Total harmonic distortion (THDi) < 3%
    AC grid connection type 3W+N+PE
    INPUT DATA
    Max.recommended PV power 20400W 21600W 22800W 24000W 25200W 26400W 27600W 28800W 30000W
    Max.DC voltage 1100V
    Start voltage 250V
    Nominal voltage 600V
    MPPT voltage range 200V-1000V
    Max.input current 26A/26A 26A/26A 26A/26A 26A/26A 26A/39A 26A/39A 26A/39A 26A/39A 26A/39A
    Number of independent MPP trackers
    / strings per MPP tracker    		 2/2 2/2 2/2 2/2 2/2+3 2/2+3 2/2+3 2/2+3 2/2+3
    DC connection H4 / MC4
    EFFICIENCY
    Max.efficiency 98.3% 98.6%
    Euro weighted efficiency 98% 98% 98% 98% 98.3% 98.3% 98.3% 98.3% 98.3%
    MPPT efficiency 99.5%
    Protection devices Island protection, DC reverse polarity protection , Output over current protection, Output overvoltage protection-varistor, Integrated DC switch, Ground fault monitoring,
    Integrated all-pole sensitive leakage current monitoring unit, DC Surge protection, AC Surge protection
    GENERAL DATA FEATURES
    Machine Dimension (W*H*D)(mm) 540*426*234
    Package Dimension (W*H*D)(mm) 650*338*542
    N.W(kg) 28.6
    G.W(kg) 32.5
    Operation temperature range -25°C- +60°C with derating above 45°C
    Noise emission(typical) ≤40dB(A)
    Altitude 3000m
    Self-consumption (night) < 1W
    Topology Transformerless
    Cooling concept Fan cooling
    Environmental protection Rating IP66
    Relative humidity 0~100%
    FEATURES
    AC connection Connector
    Display LED
    Communication interfaces WIFI/RS485/GPRS(opt)
    Warranty Standard 5 years / 10 years (opt.)
    CERTIFICATION & STANDARDS
    CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011) IEC60529; EN50549-1:2019; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G99
    ]]>         HBP1800 MT Series (3/5.2KW) https://www.mustpower.com/product/hbp1800-mt-series-3-5-2kw/ Wed, 06 Mar 2024 11:29:42 +0000 https://www.mustpower.com/?post_type=product&p=23892 Home Solar Energy Storage System 2560Wh / 3072Wh / 5120Wh Smart Power. Built for Mobility. The HBP1800 MT Series is a compact yet powerful all-in-one energy storage system, combining a high-efficiency pure sine wave inverter (3000W / 5200W) and a long-life LiFePO₄ battery pack (2560Wh / 3200Wh / 5120Wh). Designed for both stationary and portable use, it empowers your home, outdoor adventures, and emergency needs with clean, reliable energy. With MPPT solar charging capability (up to 100A) and wide PV input voltage (up to 450V), the HBP1800 MT maximizes solar energy utilization. Its intelligent control system ensures seamless UPS functionality, while the plug-and-play mobile design makes energy accessible anywhere. ]]> 🔋 Specifications
    • Inverter power: 3000W / 5200W (Pure Sine Wave)
    • DC voltage: 24V / 48V
    • Battery capacity: 2560Wh / 3200Wh / 5120Wh (LiFePO₄)
    • MPPT controller: 60A / 100A
    • PV input voltage: 150V / 450V
    • Cycle life: 6000+ cycles @ 80% DOD, 25°C

    ✅ Key Features
    ■ Built-in high-efficiency MPPT controller
    ■ Pure sine wave output – suitable for sensitive electronics
    ■ Long-life lithium battery with 6000+ cycles
    ■ Flexible UPS mode for uninterrupted power supply
    ■ Portable design for off-grid or mobile use
    ■ Supports multiple devices simultaneously with up to 11 output ports
    ■ Solar/AC/generator charging options
    ■ App remote control and real-time monitoring

    ⚡ Application Scenarios
    Whether you’re hosting an outdoor event, working remotely in a cabin, going off-grid with your RV, or preparing for power outages, the HBP1800 MT gives you the energy independence and flexibility to power through it all.

    MODEL HBP18-3024MT HBP18-5248MT
    INVERTER
    Rated power 3000W 5200W
    Output voltage waveform Pure sine wave
    Output voltage regulation 230Vac ±5%
    Output frequency 50Hz / 60Hz (±0.2Hz)
    Peak efficiency 90% 93%
    Nominal DC input voltage 24VDC 48VDC
    Standby Consumption < 25W
    PV INPUT
    Max solar power input 1800W 5000W
    PV max charging current 60A 100A
    Combined charging current 120A 1000A
    Max efficiency 98.0% max
    PV array open circuit voltage 160VDC 450VDC
    PV Array MPPT Voltage Range 30~128VDC 150~430VDC
    AC INPUT
    AC input voltage 230Vac ±5%
    Acceptable input voltage range 90~280VAC 170~280VAC
    Nominal input frequency 50Hz / 60Hz (Auto detection)
    Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
    AC CHARGE
    Charging current @ Nominal input voltage 60A 80A
    Charging Algorithm 4-step (Li)
    OUTPUT
    AC output 230Vac (Socket *4pcs)
    Type-C DC output*1pcs
    USB (5V 2.4A) DC output*4pcs
    USB (12V 1A) DC output*2pcs
    LITHIUM BATTERY
    Energy 2560Wh 3200Wh 5120Wh
    Nominal voltage 25.6V 25.6V 51.2V
    Battery capacity 100Ah 125Ah 100Ah
    Protection board 100A 150A 100A
    Standard charging & discharge current 50A 50A 100A
    Operation temperature Charge 10~45 °C
    Discharge -20~55 °C
    MECHANICAL SPECIFICATIONS
    Machine Dimension (W*H*D)(mm) 277*509*452 302*628*493
    Package Dimension (W*H*D)(mm) 380*665*555 406*810*600
    N.W(kg) 33 37 56
    G.W(kg) 39 43 65
    Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
    CERTIFICATION & STANDARDS
    *coming soon
    ]]>         HBP1800 OS Series (1.2-3KW) https://www.mustpower.com/product/hbp1800-os-series-1-2-3kw/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23878 Office Power Station 1280Wh 2560Wh 3072Wh Smart Power for Work and Life. The HBP1800 OS Series is a compact, portable solar power station engineered for office environments but flexible enough for everyday home use. With an output range of 1200W–3000W and 1280–3200Wh of built-in LiFePO₄ battery capacity, it provides reliable backup power for laptops, phones, routers, desktop computers, and more. Supporting up to MPPT 60A solar charging and wide PV input (105V–160V), the HBP1800 OS Series allows you to stay powered up with flexible recharging methods. Multiple DC outputs make plug-and-play operation simple and convenient, while its pure sine wave inverter ensures safe use with sensitive electronics. ]]> 🔋 Specifications
    • Output power: 1200W / 2000W / 3000W
    • DC voltage: 12V / 24V
    • Battery capacity: 1280Wh – 3200Wh (LiFePO₄)
    • MPPT solar charger: 60A
    • PV input voltage: 105V / 160V
    • 6000+ cycles @ 80% DOD, 25°C

    ✅ Key Features
    ■ Pure sine wave output – safe for all electronics
    ■ 6000+ charge cycles with high-quality LiFePO₄ battery
    ■ Multiple DC outputs – plug & play for all your devices
    ■ Lightweight and portable for home, office, or emergency use
    ■ Flexible charging via AC wall socket or solar panel
    ■ Built-in multi-protection system (overload, short circuit, overheating, etc.)

    ⚡ Ideal For
    • Work-from-home setups
    • Outdoor workstations
    • Office or lab backup power
    • Emergency energy backup for homes

    MODEL HBP18-1012 OS HBP18-2024 OS HBP18-3024 OS
    Nominal Battery System Voltage 12VDC 24VDC 24VDC
    INVERTER OUTPUT
    Rated power 1200W 2000W 3000W
    Output voltage waveform Pure Sine Wave
    Output voltage regulation 230V ±5%
    Output frequency 50Hz / 60Hz (±0.2Hz)
    Peak efficiency 90%
    Nominal DC input voltage 12V (±0.3) 24V (±0.3) 24V (±0.3)
    Standby Consumption < 25W
    PV INPUT
    Max solar power input 900W 1800W 1800W
    PV max charging current 60A (±3A) 60A (±3A) 60A (±3A)
    Combined charging current 70A (±4A) 100A (±4A) 120A (±4A)
    Max efficiency 98.0% max
    PV array open circuit voltage 105VDC 160VDC 160VDC
    PV Array MPPT Voltage Range 15~105V 30~128VDC 30~128VDC
    AC INPUT
    AC input voltage 230Vac ±5%
    Acceptable input voltage range 90-280VAC
    Nominal input frequency 50Hz / 60Hz (Auto detection)
    Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
    AC CHARGE
    Charging current @ Nominal input voltage 20A (±4A) 40A/(±4A) 60A (±4A)
    Charging Algorithm 4-step (Li)
    OUTPUT
    AC output 230Vac (Socket *3pcs)
    USB TypeC DC output*1pcs
    USB-A 12V/1A DC output*2pcs
    USB-A 5V DC output*4pcs
    LITHIUM BATTERY
    Energy 1280Wh 2560Wh 3200Wh
    Nominal voltage 12.8V 25.6V 25.6V
    Battery capacity 100Ah 100Ah 125Ah
    Protection board 100A 100A 150A
    Standard charging & discharge current 50A 50A 50A
    Operation temperature Charge 0°C to 45°C
    Discharge -10°C to 60°C
    MECHANICAL SPECIFICATIONS
    Machine Dimension (W*H*D)(mm) 225*295*363 275*324*403 288*348*490
    Package Dimension (W*H*D)(mm) 440*305*355 485*356*420 570*370*445
    N.W(kg) 17 24 33
    G.W(kg) 18.5 26 36
    Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
    CERTIFICATION & STANDARDS
    CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
    ]]>         HBP1800 Series (1.2-4KW) https://www.mustpower.com/product/hbp1800-series-1-2-4kw/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23880 Home Solar Energy Storage System 1.2~4KW | 12V, 24V | 1280Wh~7168Wh Modular Power. Anytime, Anywhere. The MUST HBP1800 Series offers a smart and flexible energy storage solution tailored for residential, educational, commercial, and public utility applications. With an output range from 1.2kW to 4kW and a stackable battery capacity of 1280Wh to 7168Wh, this all-in-one system combines a pure sine wave inverter, a LiFePO₄ battery, and an intelligent battery management system, all housed in a compact, cabinet-style design. Its plug & play functionality and 11 output ports for DC loads make it ideal for users seeking a reliable off-grid power backup or hybrid solution with high safety standards and long life cycles. ]]> 🔋 Specifications
    • Inverter output: 1200W / 2000W / 3000W / 4000W
    • DC voltage: 12V / 24V
    • PV input: 106V / 160V
    • Battery capacity: 1280Wh – 7168Wh (LiFePO₄)
    • Cycle life: 4000+ @ 80% DOD, 25°C

    ✅ Key Features
    ■ Pure sine wave inverter – stable power for all loads
    ■ Modular & stackable design – customize capacity as needed
    ■ 4000+ charge cycles – reliable long-term performance
    ■ 11 DC output ports – connect multiple devices simultaneously
    ■ 24/7 plug & play use – ready for anytime backup
    ■ Built-in BMS – protection from overcharge, short-circuit, over-discharge, etc.
    ■ Quiet operation & compact footprint

    ⚡ Ideal For
    • Residential backup & off-grid living
    • Schools and classrooms
    • Commercial shops and kiosks
    • Public infrastructure & rural energy access

    MODEL HBP18-1212 HBP18-2024 HBP18-3024 HBP18-4024
    INVERTER
    Rated power 1200W 2000W 3000W 4000W
    Surge power 2400W 4000W 6000W 8000W
    Output voltage waveform Pure sine wave
    Output voltage regulation 220~240Vac(setting)
    Output frequency 50Hz / 60Hz (±0.2Hz)
    Peak efficiency 90~93%
    Nominal DC input voltage 12Vdc (±0.3) 24Vdc (±0.3) 24Vdc (±0.3) 24Vdc (±0.3)
    Standby Consumption < 25W
    PV INPUT
    Max solar power input 900W 1800W 1800W 1800W
    PV max charging current 60A (±3A) 60A (±3A) 60A (±3A) 60A (±3A)
    Combined charging current 70A (±4A) 100A (±4A) 120A (±4A) 120A (±4A)
    Max efficiency 98.0% max
    PV array open circuit voltage 105VDC 160VDC 160VDC 160VDC
    PV Array MPPT Voltage Range 15~105V 30~128VDC 30~128VDC 30~128VDC
    AC INPUT
    AC input voltage 230Vac ±5%
    Acceptable input voltage range 90-280VAC
    Nominal input frequency 50Hz / 60Hz (Auto detection)
    Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
    AC CHARGE
    Charging current @ Nominal input voltage 20A (±4A) 40A/(±4A) 60A (±4A) 60A (±4A)
    Charging Algorithm 4-step (Li)
    OUTPUT
    AC output 230Vac (Socket *4pcs)
    Type-C DC output*1pcs
    USB (5V 2.4A) DC output*4pcs
    USB (12V 1A) DC output*2pcs
    LITHIUM BATTERY
    Energy 1280Wh 2560Wh 3072Wh 7168Wh 7168Wh
    Nominal voltage 12.8V 25.6V 25.6V 25.6V
    Battery capacity 100Ah 100Ah 120Ah 280Ah 280Ah
    Protection board 100A 100A 150A 150A
    Standard charging & discharge current 50A 50A 50A 50A 50A
    Operating temperature Charge 0~45°C
    Discharge -10~60°C
    DIMENSION
    Machine Dimension (W*H*D)(mm) 359*499*234 420*497*280 460*539*411 460*539*411
    Package Dimension (W*H*D)(mm) 460*560*335 522*655*382 570*702*521 570*702*521
    N.W(kg) 21 30 36 66 67
    G.W(kg) 26 41 45 80 81
    Standard Warranty Inverter: 2 years ; Lithium battery: 3 years
    CERTIFICATION & STANDARDS
    CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2); IEC62368-1
    ]]>
