110/120V ESS – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Tue, 24 Dec 2024 09:17:32 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 HBP1800 LV Series (AC:120V 1/2kW) https://www.mustpower.com/product/hbp1800-lv-series-ac120v-1-2kw/ Tue, 24 Dec 2024 09:03:21 +0000 https://www.mustpower.com/?post_type=product&p=24861 Solar power station 1/2KW | 12V,24V | 120VAC | 1280Wh 2560Wh MUST HBP1800 LV series all-in-one energy storage solution, support 1KW/2KW output for different load appliances. It's based on the original cabinet design, stacked with solar energy storage lithium battery 1280wh~2560wh, and built in battery protection system, fully retain the use of load power in applications of residential, school, commercial and public utility area.]]> ■ Supports 120V and 240V split-phase output
■ Energy storage 1280~2560wh Optional
■ 6000+ Charge cycle @ 80% DOD,25°C
■ 1~2KW Pure sine wave inverter
■ Multiple DC output ports for Multiple Devices, Plug & play
■ Flexible Recharging Ways (AC/ Solar)
■ Built in Multi safety protection

MODEL HBP18-1012 LV HBP18-2024 LV
Nominal Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated power 1000W 2000W
Output voltage waveform Pure Sine Wave
Output voltage regulation 120V ±5%
Output frequency 50Hz / 60Hz (±0.2Hz)
Peak efficiency 90%
Nominal DC input voltage 12V (±0.3) 24V (±0.3)
Standby Consumption < 25W
PV INPUT
Max solar power input 900W 1800W
PV max charging current 60A (±3A) 60A (±3A)
Max combined charging current 70A (±4A) 100A (±4A)
Max efficiency 98.0% max
PV array open circuit voltage 105VDC 160VDC
PV Array MPPT Voltage Range 15~105V 30~128VDC
AC INPUT
AC input voltage 120Vac ±5%
Acceptable input voltage range 107~132VAC(UL)
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
AC CHARGE
Charging current @ Nominal input voltage 10A (±4A) 40A(±4A)
Charging Algorithm 4-step (Li)
OUTPUT
AC output 120Vac (Socket *4pcs)
USB TypeC DC output*1pcs
USB-A 12V/1A DC output*2pcs
USB-A 5V DC output*4pcs
LITHIUM BATTERY
Energy 1280Wh 2560Wh
Nominal voltage 12.8V 25.6V
Battery capacity 100Ah 100Ah
Protection board 100A 100A
Standard charging & discharge current 50A 50A
Operation temperature Charge 0°C to 45°C
Discharge -10°C to 60°C
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 359*499*234 420*497*280
Package Dimension (W*H*D)(mm) 460*560*335 522*655*382
N.W(kg) 21 30
G.W(kg) 26 41
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> HBP1800 OLV Series (AC:120V 1/2KW) https://www.mustpower.com/product/hbp1800-olv-series-ac120v-1-2kw/ Wed, 29 May 2024 10:07:14 +0000 https://www.mustpower.com/?post_type=product&p=24387 Portable Power Station DC 12V,24V | AC 120V | 1280Wh 2560Wh The HBP1800 OLV series is specifically designed for office use, providing a reliable and efficient power source. However, it is also versatile enough to power various household appliances, including phone, laptops, stereos, and desktop computers. Equipped with a built-in LiFePO4 battery, the HBP1800 OLV has a capacity of either 1280Wh or 2560Wh, Multiple DC output ports for Multiple Devices, Plug & play, making it an ideal portable power station for a range of needs.]]> ■ Energy storage 1280~2560wh Optional
■ 6000+ Charge cycle @ 80% DOD,25°C
■ 1~3KW Pure sine wave inverter
■ Multiple DC output ports for Multiple Devices, Plug & play
■ Flexible Recharging Ways (AC/ Solar)
■ Built in Multi safety protection

MODEL HBP18-1012 OLV HBP18-2024 OLV
Nominal Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated power 1000W 2000W
Output voltage waveform Pure Sine Wave
Output voltage regulation 120V ±5%
Output frequency 50Hz / 60Hz (±0.2Hz)
Peak efficiency 90%
Nominal DC input voltage 12V (±0.3) 24V (±0.3)
Standby Consumption < 25W
PV INPUT
Max solar power input 900W 1800W
PV max charging current 60A (±3A) 60A (±3A)
Max combined charging current 70A (±4A) 100A (±4A)
Max efficiency 98.0% max
PV array open circuit voltage 105VDC 160VDC
PV Array MPPT Voltage Range 15~105V 30~128VDC
AC INPUT
AC input voltage 120Vac ±5%
Acceptable input voltage range 107~132VAC(UL)
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
AC CHARGE
Charging current @ Nominal input voltage 10A (±4A) 40A(±4A)
Charging Algorithm 4-step (Li)
OUTPUT
AC output 120Vac (Socket *3pcs)
USB TypeC DC output*1pcs
USB-A 12V/1A DC output*2pcs
USB-A 5V DC output*4pcs
LITHIUM BATTERY
Energy 1280Wh 2560Wh
Nominal voltage 12.8V 25.6V
Battery capacity 100Ah 100Ah
Protection board 100A 100A
Standard charging & discharge current 50A 50A
Operation temperature Charge 0°C to 45°C
Discharge -10°C to 60°C
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 225*295*363 275*324*403
Package Dimension (W*H*D)(mm) 440*305*355 485*356*420
N.W(kg) 17 /
G.W(kg) 18.5 /
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> HBP1100 LV Series (AC:120V 3.5/4KW) https://www.mustpower.com/product/hbp1100-lv-series-ac120v-3-5-4kw/ Wed, 29 May 2024 10:01:30 +0000 https://www.mustpower.com/?post_type=product&p=24385 All-in-One ESS 5120Wh/10240Wh/15360Wh | PV 500V | 120VAC HBP1100 PRO energy storage system is an all-in-one solution, which integrated a hybrid solar inverter & lithium battery in to one unit. This model combines functions both off grid and on grid which could manage your solar home battery storage easily. Flexible modular system could be designed based on house dailyconsumption. ESS is easily to select the priority of power supply, it allows you to store the energy to self-consumption and sell to the grid. ESS is the best emergency energy solution for villas, apartments,hotels,shopping centers.]]> ■ Lithium Battery Modular 5120Wh/10240Wh/15360Wh
■ Self-consumption and feed-back to the grid
■ Multiple Working Mode: Energy storage mode, load priority mode, power selling mode,and a high-efficiency mode (six time periods are provided for setting different modes to achieve peak-shaving and valley-filling, maximizing economic benefits)
■ Inside BMS,support to be charged and discharged according to bms requirements
■ Support to connect with generator
■ Automatic line-to-battery switch over

MODEL HBP11-3648 LV HBP11-4048 LV
Rated power 3600W 4000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4000W 5000W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER OUTPUT(AC)
Nominal AC output power 3600W 4000W
Nominal output voltage; range 110/120/130V; 90~140V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal output current 30A 34A
Maximum output current 33A 36A
Inrush current (spike/duration) 72A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading~0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 30A 34A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s
Total harmonic distortion (linear load) <3%
BATTERY & CHARGER
Note: Below Parameters base on one LiFePO4 Lithium Battery Modular
Battery parameter 51.2VDC 100Ah
Number of battery pack 1 2 2 3
Capacity 5120Wh 10240Wh 10240Wh 15360Wh
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W
Maximum charging currernt 75A 85A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) (Inverter+Battery) 594*1154*220(5120Wh); 594*1559*220 (10240Wh); 594*1964*220 (15360Wh)
Package Dimension (W*H*D)(mm) Inverter 900*335*714
Battery 666*280*483 (Single Battery)
N.W(kg) Inverter 42
Battery(51.2V100Ah) 52
G.W(kg) Inverter 55
Battery(51.2V100Ah) 57
Standard Warranty Inverter: 5 years ; Lithium battery: 5 years
OTHER
Operating Temperature Range -15°C to 40°C
Ingress protection rating IP66
Audible Noise 60dB MAX
Display LED+LCD
CERTIFICATION & STANDARDS
CE-EMC
]]> HBP3300 TLV Series (AC:120V+120V 2-6KW) https://www.mustpower.com/product/hbp3300-tlv-series-ac120v120v-2-6kw/ Wed, 06 Mar 2024 11:29:42 +0000 https://www.mustpower.com/?post_type=product&p=23889 All in One Home Solar Energy Storage System (AC:120V/220V) 7168/14338Wh The MUST HBP3300 TLV Series is with a ground-breaking LiFePO4 battery pack 7.16kwh and 14.33kwh energy storage, pure sine wave solar inverter inbuilt. Versatile energy storage system as your home strong back up, reliable access to power sources anytime. This class-leading power station brings you the power to run your daily consumes, family camping trip, cabin workshops, or even whole house for a day or two days power back up depending on your demands.]]> ■ Split Phase Power Inverter
■ Stacked movable energy storage systems
■ Rechargeable lithium batteries use safe lithium cell LiFePO4
■ The intelligent BMS system adopts the latest battery communication system
■ Reduce electricity bills and increase your energy needs for electrical self-sufficiency.

MODEL HBP33-2024 TLV HBP33-3024 TLV HBP33-5048 TLV HBP33-6048 TLV
INVERTER
Rated power 2000W 3000W 5000W 6000W
Output voltage waveform Pure sine wave
Output voltage regulation 100V / 110V / 120VAC (200V/220V/ 240VAC, L+L) ±10%
Output frequency 50Hz or 60Hz (±0.2Hz)
Peak efficiency 85%
Nominal DC input voltage 24Vdc 48Vdc
Standby Consumption < 2W
PV INPUT
Max solar power input 2500W 5000W
PV max charging current 80A
Combined charging current 80A
Max efficiency 98% max
PV array open circuit voltage 245VDC
PV Array MPPT Voltage Range 30~230VDC 64~230VDC
AC INPUT
AC input voltage 200/220/240VAC
Acceptable input voltage range 150~265VAC
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms(max)
AC CHARGE
Charging current @ Nominal input voltage 30A 40A 35A 40A
Charging Algorithm 4-step (Li)
OUTPUT
AC output Terminal & Socket (10A max)
LITHIUM BATTERY
Energy 7168wh 14338wh
Nominal voltage 25.6V 51.2V
Battery capacity 280Ah
Standard charging and discharge current 100A
Maximum continuous charging & discharge current 100A
Operation ambient temperature -10~50°C
Storage ambient temperature -20~55°C
DIMENSION
Machine Dimension (W*H*D)(mm) (Inverter+Battery) 620*865*610 640*992*600
Package Dimension (W*H*D)(mm) Inverter 617*297*587
Battery 620*610*568 640*695*600
N.W(kg) Inverter 23.2 36.0
Battery / 115
G.W(kg) Inverter 25.7 38.5
Battery / 135
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC
]]> HBP3000 LV Series (AC:120V 1.5-6KW) https://www.mustpower.com/product/hbp3000-lv-series-ac120v-1-5-6kw/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23888 All in One Home Solar Energy Storage System (AC:120V) 7168/14336Wh The MUST HBP3000 LV Series is with a ground-breaking LiFePO4 battery pack 7.16kwh and 14.33kwh energy storage, pure sine wave solar inverter inbuilt. Versatile energy storage system as your home strong back up, reliable access to power sources anytime. This class-leading power station brings you the power to run your daily consumes, family camping trip, cabin workshops, or even whole house for a day or two days power back up depending on your demands.]]> ■ Stacked movable energy storage systems
■ Rechargeable lithium batteries use safe lithium cell LiFePO4
■ The intelligent BMS system adopts the latest battery communication system
■ Reduce electricity bills and increase your energy needs for electrical self-sufficiency.

MODEL HBP30-1524 LV HBP30-2024 LV HBP30-3024 LV HBP30-5048 LV HBP30-6048 LV
INVERTER
Rated power 1500W 2000W 3000W 5000W 6000W
Output voltage waveform Pure sine wave
Output voltage regulation 110V/115V/120V ±10%
Output frequency 50Hz or 60Hz (±0.2Hz)
Peak efficiency 88%
Nominal DC input voltage 24Vdc 48Vdc
Standby Consumption < 2W
PV INPUT
Max solar power input 2500W 5000W
PV max charging current 80A
Combined charging current 80A
Max efficiency 98% max
PV array open circuit voltage 245V
PV Array MPPT Voltage Range 30~230VDC 60~230VDC
AC INPUT
AC input voltage 120Vac ±5%
Acceptable input voltage range 96~132VAC
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms(max)
AC CHARGE
Charging current @ Nominal input voltage 25A 30A 40A 35A 40A
Charging Algorithm 4-step (Li)
OUTPUT
AC output Terminal & Socket (10A max)
LITHIUM BATTERY
Energy 7168wh 14336wh
Nominal voltage 25.6V 51.2V
Battery capacity 280Ah
Standard charging and discharge current 100A
Maximum continuous charging & discharge current 100A
Operation ambient temperature Charge -10~50℃
Discharge -20~55℃
DIMENSION
Machine Dimension (W*H*D)(mm) (Inverter+Battery) 620*865*610 640*992*600
Package Dimension (W*H*D)(mm) Inverter 617*297*587
Battery 620*568*610 640*695*600
N.W(kg) Inverter / / 25.6 / 35.7
Battery / / / 115
G.W(kg) Inverter / / 27.9 / 38
Battery / / / 135
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC
]]>
