Americas Products – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Tue, 24 Dec 2024 09:17:32 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 HBP1100 US Series (5-10kW) https://www.mustpower.com/product/hbp1100-us-series-5-10kw/ Tue, 24 Dec 2024 09:16:38 +0000 https://www.mustpower.com/?post_type=product&p=24866 Split-Phase All-in-One Energy Storage System 5~10KW | 10240Wh | IP66 | 120V/240V Equipped with 120V/240V split-phase output and IP66 protection, HBP1100 US offers flexibility in installation and dependable performance indoors or outdoors. With a robust 10.2kWh capacity for whole-home backup and support for up to 10kW PV input, optimizes energy usage, helping users save on electricity bills while ensuring uninterrupted power supply. Ideal for homeowners seeking sustainable energy solutions without compromising on power reliability, HBP1100 US sets a new standard in home energy storage technology.]]> ■ 120V/240V Split-phase output
■ 2 MPPTs with 2 strings, Max. PV input 10kW
■ 200Ah battery cells, long cycle life
■ 10.24kWh battery modules
■ IP66 protection rating, install anywhere
■ WiFi remote monitoring
■ Enhanced safety features using advanced hardware & software protection

MODEL HBP11-5K US HBP11-6K US HBP11-8K US HBP11-10K US
Rated power 5000W 6000W 8000W 10000W
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~500V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 5000W 6000W 8000W 10000W
Max AC Input/ Output Power 5000W 6000W 8000W 10000W
AC Input/ Output Rated Current 20.8A/19.2A 25A/23A 33.3A/30.7A 41.6A/38.4A
Rated Input/Output Voltage/Range 120V/240V:208V
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Split Phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%
BATTERY & CHARGER
Battery parameter 51.2VDC 200Ah
Capacity 10240Wh
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Note: Below Parameters base on one LiFePO4 Lithium Battery Modular
GENERAL DATA
Operating Temperature Range (°C) -15°C~+40°C
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) /
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
cpmming soon
]]> HBP1800 LV Series (AC:120V 1/2kW) https://www.mustpower.com/product/hbp1800-lv-series-ac120v-1-2kw/ Tue, 24 Dec 2024 09:03:21 +0000 https://www.mustpower.com/?post_type=product&p=24861 Solar power station 1/2KW | 12V,24V | 120VAC | 1280Wh 2560Wh MUST HBP1800 LV series all-in-one energy storage solution, support 1KW/2KW output for different load appliances. It's based on the original cabinet design, stacked with solar energy storage lithium battery 1280wh~2560wh, and built in battery protection system, fully retain the use of load power in applications of residential, school, commercial and public utility area.]]> ■ Supports 120V and 240V split-phase output
■ Energy storage 1280~2560wh Optional
■ 6000+ Charge cycle @ 80% DOD,25°C
■ 1~2KW Pure sine wave inverter
■ Multiple DC output ports for Multiple Devices, Plug & play
■ Flexible Recharging Ways (AC/ Solar)
■ Built in Multi safety protection

MODEL HBP18-1012 LV HBP18-2024 LV
Nominal Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated power 1000W 2000W
Output voltage waveform Pure Sine Wave
Output voltage regulation 120V ±5%
Output frequency 50Hz / 60Hz (±0.2Hz)
Peak efficiency 90%
Nominal DC input voltage 12V (±0.3) 24V (±0.3)
Standby Consumption < 25W
PV INPUT
Max solar power input 900W 1800W
PV max charging current 60A (±3A) 60A (±3A)
Max combined charging current 70A (±4A) 100A (±4A)
Max efficiency 98.0% max
PV array open circuit voltage 105VDC 160VDC
PV Array MPPT Voltage Range 15~105V 30~128VDC
AC INPUT
AC input voltage 120Vac ±5%
Acceptable input voltage range 107~132VAC(UL)
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
AC CHARGE
Charging current @ Nominal input voltage 10A (±4A) 40A(±4A)
Charging Algorithm 4-step (Li)
OUTPUT
AC output 120Vac (Socket *4pcs)
USB TypeC DC output*1pcs
USB-A 12V/1A DC output*2pcs
USB-A 5V DC output*4pcs
LITHIUM BATTERY
Energy 1280Wh 2560Wh
Nominal voltage 12.8V 25.6V
Battery capacity 100Ah 100Ah
Protection board 100A 100A
Standard charging & discharge current 50A 50A
Operation temperature Charge 0°C to 45°C
Discharge -10°C to 60°C
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 359*499*234 420*497*280
Package Dimension (W*H*D)(mm) 460*560*335 522*655*382
N.W(kg) 21 30
G.W(kg) 26 41
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> PH1800 TLV Series (AC:110/220V 6KW) https://www.mustpower.com/product/ph1800-tlv-series-ac110-220v-6kw/ Sun, 29 Sep 2024 02:31:47 +0000 https://www.mustpower.com/?post_type=product&p=24593 High Frequency On/Off Hybrid Solar Inverter PV 250V | MPPT 80A | DC 48V This split phase solar inverter PH1800 TLV series, capacity 6KW, DC 48V, it’s applicable to 110VAC/120VAC markets demands, which has AC output of single phase 110VAC/120V, split phase 220V/240V; In LCD display, you can set output voltage, frequency, charging voltage, charging current to design best use based on different loads applications; meanwhile, it has built-in two 80A MPPT solar charge controllers, you can take use of sunshine freely and save electricity bills.]]> ■ Pure sine wave solar inverter
■ Output power factor 1
■ Built-in two 80A MPPT solar charge controllers
■ WIFI remote monitoring (optional)
■ Acid or Lithium Battery Select
■ CAN/RS485 communication for BMS
■ Compatible to generator

MODEL PH18-6048 TLV
Nominal Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6000W
Surge Power 12000VA
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 120VAC/240VAC (L1/L2)
Inverter Efficiency(Peak) 90%~93%
Transfer Time 10ms (UPS / UL) 20ms (APL)
AC INPUT
Voltage 240VAC (L1/L2/N)
Selectable Voltage Range 214~264VAC(UL)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 250V
Maximum Solar Charge Current 80A/80A
PV Array MPPT Voltage Range 60~200VDC
PV Input Power 4000W/4000W
Maximum Efficiency 98%
Maximum AC Charge Current 60A/60A
Maximum Charge Current 280A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 318*560*249
Package Dimension (W*H*D)(mm) 678*345*420
N.W(kg) 21.5
G.W(kg) 24
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature -10°C~50°C
Storage Temperature -15°C~60°C
Standard Warranty 2years
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1, EN IEC62109-2); UKCA-(BS EN 62109-1, BS EN 62109-2)
]]> PH1100 US Series (Split Phase 5-10KW) https://www.mustpower.com/product/ph1100-us-series-split-phase-5-10kw/ Wed, 26 Jun 2024 03:54:36 +0000 https://www.mustpower.com/?post_type=product&p=24459 Split Phase Hybrid Solar Inverter | AC 240/120V | DC 48V | PV 370V PH1100 US is brand new split phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and highpower density, this series supports 1.3 DC/AC ratio, saving device investment. It’s applicable to 110VAC/120VAC markets demands, which matches AC 110VAC/120V single phase, or two phase 220V/240V; Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.]]> ■ 100% unbalanced output, each phase max. output up to 50% rated power
■ Max. 6 pcs parallel for on-grid and off-grid operation
■ AC couple to retrofifit existing solar system
■ Support multiple batteries parallel
■ Max. charging/discharging current of 220A
■ Support storing energy from diesel generator
■ 48V low voltage battery, transformer isolation design
■ IP66 water-proof and dust-proof
■ “Time of use” function: a maximum of 6 time segments can be set
■ Wifi monitoring

MODEL PH11-5KL2-US PH11-6KL2-US PH11-8KL2-US PH11-10KL2-US
Rated power 5000W 6000W 8000W 10000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~64V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 5000W 6000W 8000W 10000W
Maximum charging/discharging current 110A 130A 170A 220A
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~500V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 5000W 6000W 8000W 10000W
Max AC Input/ Output Power 5000W 6000W 8000W 10000W
AC Input/ Output Rated Current 20.8A/19.2A 25A/23A 33.3A/30.7A 41.6A/38.4A
Rated Input/Output Voltage/Range 120V/240V:208V
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Split Phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%
PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection, PV input polarity reverse protection, DC Switch (optional), Ground Fault Sensing, leakage current monitoringprotection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 816*404*567
N.W(kg) 38
G.W(kg) 42
Warranty 5 Year
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
CERTIFICATION & STANDARDS
NBT32004-2013
]]> HBP1800 OLV Series (AC:120V 1/2KW) https://www.mustpower.com/product/hbp1800-olv-series-ac120v-1-2kw/ Wed, 29 May 2024 10:07:14 +0000 https://www.mustpower.com/?post_type=product&p=24387 Portable Power Station DC 12V,24V | AC 120V | 1280Wh 2560Wh The HBP1800 OLV series is specifically designed for office use, providing a reliable and efficient power source. However, it is also versatile enough to power various household appliances, including phone, laptops, stereos, and desktop computers. Equipped with a built-in LiFePO4 battery, the HBP1800 OLV has a capacity of either 1280Wh or 2560Wh, Multiple DC output ports for Multiple Devices, Plug & play, making it an ideal portable power station for a range of needs.]]> ■ Energy storage 1280~2560wh Optional
■ 6000+ Charge cycle @ 80% DOD,25°C
■ 1~3KW Pure sine wave inverter
■ Multiple DC output ports for Multiple Devices, Plug & play
■ Flexible Recharging Ways (AC/ Solar)
■ Built in Multi safety protection

MODEL HBP18-1012 OLV HBP18-2024 OLV
Nominal Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated power 1000W 2000W
Output voltage waveform Pure Sine Wave
Output voltage regulation 120V ±5%
Output frequency 50Hz / 60Hz (±0.2Hz)
Peak efficiency 90%
Nominal DC input voltage 12V (±0.3) 24V (±0.3)
Standby Consumption < 25W
PV INPUT
Max solar power input 900W 1800W
PV max charging current 60A (±3A) 60A (±3A)
Max combined charging current 70A (±4A) 100A (±4A)
Max efficiency 98.0% max
PV array open circuit voltage 105VDC 160VDC
PV Array MPPT Voltage Range 15~105V 30~128VDC
AC INPUT
AC input voltage 120Vac ±5%
Acceptable input voltage range 107~132VAC(UL)
Nominal input frequency 50Hz / 60Hz (Auto detection)
Transfer time 10ms typical (UPS, VDE); 20ms typical (APL)
AC CHARGE
Charging current @ Nominal input voltage 10A (±4A) 40A(±4A)
Charging Algorithm 4-step (Li)
OUTPUT
AC output 120Vac (Socket *3pcs)
USB TypeC DC output*1pcs
USB-A 12V/1A DC output*2pcs
USB-A 5V DC output*4pcs
LITHIUM BATTERY
Energy 1280Wh 2560Wh
Nominal voltage 12.8V 25.6V
Battery capacity 100Ah 100Ah
Protection board 100A 100A
Standard charging & discharge current 50A 50A
Operation temperature Charge 0°C to 45°C
Discharge -10°C to 60°C
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 225*295*363 275*324*403
Package Dimension (W*H*D)(mm) 440*305*355 485*356*420
N.W(kg) 17 /
G.W(kg) 18.5 /
Standard Warranty Inverter: 2 years ; Lithium battery: 5 years
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3;2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> HBP1100 LV Series (AC:120V 3.5/4KW) https://www.mustpower.com/product/hbp1100-lv-series-ac120v-3-5-4kw/ Wed, 29 May 2024 10:01:30 +0000 https://www.mustpower.com/?post_type=product&p=24385 All-in-One ESS 5120Wh/10240Wh/15360Wh | PV 500V | 120VAC HBP1100 PRO energy storage system is an all-in-one solution, which integrated a hybrid solar inverter & lithium battery in to one unit. This model combines functions both off grid and on grid which could manage your solar home battery storage easily. Flexible modular system could be designed based on house dailyconsumption. ESS is easily to select the priority of power supply, it allows you to store the energy to self-consumption and sell to the grid. ESS is the best emergency energy solution for villas, apartments,hotels,shopping centers.]]> ■ Lithium Battery Modular 5120Wh/10240Wh/15360Wh
■ Self-consumption and feed-back to the grid
■ Multiple Working Mode: Energy storage mode, load priority mode, power selling mode,and a high-efficiency mode (six time periods are provided for setting different modes to achieve peak-shaving and valley-filling, maximizing economic benefits)
■ Inside BMS,support to be charged and discharged according to bms requirements
■ Support to connect with generator
■ Automatic line-to-battery switch over

MODEL HBP11-3648 LV HBP11-4048 LV
Rated power 3600W 4000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4000W 5000W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER OUTPUT(AC)
Nominal AC output power 3600W 4000W
Nominal output voltage; range 110/120/130V; 90~140V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal output current 30A 34A
Maximum output current 33A 36A
Inrush current (spike/duration) 72A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading~0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 30A 34A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s
Total harmonic distortion (linear load) <3%
BATTERY & CHARGER
Note: Below Parameters base on one LiFePO4 Lithium Battery Modular
Battery parameter 51.2VDC 100Ah
Number of battery pack 1 2 2 3
Capacity 5120Wh 10240Wh 10240Wh 15360Wh
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W
Maximum charging currernt 75A 85A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) (Inverter+Battery) 594*1154*220(5120Wh); 594*1559*220 (10240Wh); 594*1964*220 (15360Wh)
Package Dimension (W*H*D)(mm) Inverter 900*335*714
Battery 666*280*483 (Single Battery)
N.W(kg) Inverter 42
Battery(51.2V100Ah) 52
G.W(kg) Inverter 55
Battery(51.2V100Ah) 57
Standard Warranty Inverter: 5 years ; Lithium battery: 5 years
OTHER
Operating Temperature Range -15°C to 40°C
Ingress protection rating IP66
Audible Noise 60dB MAX
Display LED+LCD
CERTIFICATION & STANDARDS
CE-EMC
]]> EP1800 LV Series (3KW) https://www.mustpower.com/product/ep1800-lv-series-3kw/ Fri, 24 May 2024 07:06:25 +0000 https://www.mustpower.com/?post_type=product&p=24287 High Frequency Power Inverter/Charger DC 24V | AC 120V This is a multi-function inverter/charger, combining functions of inverter, battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger priority, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ Smart battery charger design for optimized battery performance
■ Acid or Lithium select
■ Parallel operation with up to 3 units
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)

MODEL EP18-3024LV
Rated output power 3000VA/3000W
Surge Power 6000W
AC INPUT
Nominal Input Voltage 120Vac±5%
Selectable Voltage range 90~145VAC(UPS) / 74~145VAC(APL) / 108~132VAC(UL)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 95%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 120Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / UL) / 20ms (APL) <50ms(For parallel operation)
Nominal DC Input Voltage 24VDC
Cold Start Voltage 23VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 24VDC
Floating voltage 27.4V
Overcharge Protection 30V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 28.8Vdc
Floating Charging Voltage 27.4Vdc
Charging Algorithm 3-Step
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 297.5*468*125
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
GENERAL
Mounting Wall mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10°C to 50°C
Storage Temperature -15°C to 60°C
Standard Warranty 2 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-4,EN6100-6-2+EN IEC62109-1)
]]> PH1100 LV Series (AC120V: 3.6/4KW) https://www.mustpower.com/product/ph1100-lv-series-ac120v-3-6-4kw/ Wed, 24 Apr 2024 03:31:31 +0000 https://www.mustpower.com/?post_type=product&p=24152 High Frequency On/Off Hybrid Solar Inverter 3.6/4KW | AC 120V | PV 500V | IP65 This is a flexible and intelligent energy storage solar inverter with a wide range of MPPT Voltage. Combining functions of off grid and on grid. This hybrid solar inverter can power all kinds of appliances in home or office, and can also be used in power stations.]]> ■ Multiple operation modes: Grid-tie,off grid with storage backup
■ IP65 water-proof and dust-proof
■ MPPT voltage range 120-500V
■ Support LCD display&Smart LCD setting
■ Available Export control CT sensor function
■ Multiple communications:USB,RS485,GPRS and wifi etc
■ Full protection function:Over-voltage,over-frequency, over-current, over-temperature,and AC short-circuit automatic protection
■ Intelligent BMS battery management function
■ Fanless low-noise design
■ Wifi monitoring

MODEL PH11-3648 LV PH11-4048 LV
Rated Power 3600W 4000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4600W 5200W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER INPUT/ OUTPUT(AC)
Nominal AC input/ output power 3600W 4000W
Nominal input/ output voltage; range 110/120/130V; 90~140V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal input/ output current 30A 34A
Maximum input/ output current 33A 36A
Inrush current (spike/duration) 72A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading ～ 0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 30A 34A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s
Total harmonic distortion v (linear load) <3%
BATTERY & CHARGER
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~60V
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W
Maximum charging currernt 75A 85A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 420*480*215
Package Dimension (W*H*D)(mm) 610*324*595
N.W(kg) 30
G.W(kg) 32
GENERAL
DC connection H4 / MC4
AC connection Terminal Block
Display LED+LCD
Communication interfaces Wi-Fi / USB / GPRS / RS485
Ingress protection rating IP65
Humidity 0~95% RH(No codensing)
Operating temperature range -20°C+60°C With derating above 45°C
Cooling concept Natural
Altitude <3000m
Standard Warranty 5years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011); CE-LVD(EN62477-1:2022) IEC60529; EN50549-1:2019; Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021), C10/C11; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G98+G99
]]> PV2900 LHP Series (AC:110V 1-6KW) https://www.mustpower.com/product/pv2900-lhp-series-ac110v-1-6kw/ Tue, 23 Apr 2024 11:35:14 +0000 https://www.mustpower.com/?post_type=product&p=24140 Low Frequency Solar Inverter AC 120V | MPPT 80A | WIFI | BMS | Dual output PV2900 LHP series is very economical pure sine wave solar inverter, AC voltage 110V/120V, AC charger inbuilt, from 20A to 60A; MPPT solar charger 80A inbuilt; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is not enough, it enables inverter to operate with all kinds of home appliances, widely selling to Latin America.]]> ■ Pure sine wave output
■ 3 Steps charging
■ Overload and short-circuit protection
■ Set charging voltage/charging current.
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Power-save mode
■ Set utility priority/ Battery priority
■ Set utility input wide/narrow range
■ Inverter voltage can be set to 120V:110V/115V/120V
■ Inverter frequency can be set to 50/60Hz
■ Set utility charging on/off switch
■ 80A MPPT charger
■ Acid or Lithium Select
■ WiFi port (optional)
■ With BMS lithium battery communication function (CAN port)
■ Dual output for smart load management

MODEL PV29-1KW-LHP PV29-1.5KW-LHP PV29-2KW-LHP PV29-3KW-LHP PV29-4KW-LHP PV29-5KW-LHP PV29-6KW-LHP
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1 KW 1.5 KW 2 KW 3 KW 4 KW 5 KW 6 KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1P 1P 1.5P 2P 3P
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 110V / 115V / 120VAC(±10% RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 110/120VAC
Selectable Voltage Range 75~135VAC (For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Alarm (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Cut Off 10V / 10.5V / 11V / 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Idie Consumption-Search Mode Load ≤50±20W(120V)/100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Overcharge Protection S.D. 15.5VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
PAYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/40A 4-6K/63A
SOLAR CHARGER
Maximum PV Array Power 1250W 2500W 1250W 2500W 1250W 2500W 2500W 5000W 2500W 5000W 5000W 5000W
Maximum PV Charge Current 80A±4A
DC Voltage 12V/ 24V auto work 24V/ 48V auto work
MPPT Range @ Operating Voltage 15~95VDC @ 12V/ 30~230VDC @ 24V 30~230VDC @ 24V/ 60~230VDC @ 48V
Maximum PV Array Open Circuit Voltage 245VDC
Standby Power Consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Machine Dimension (W*H*D)(mm) 274*484*174 274*568.5*174
Package Dimension (W*H*D)(mm) 583.5*255*376 668.5*255*376
N.W(kg) / /
G.W(kg) / /
OTHER
Operating Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 2 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> EH2900 LV Series (AC:110V 300-1000W) https://www.mustpower.com/product/eh2900-lv-series-ac110v-300-1000w/ Tue, 23 Apr 2024 11:16:54 +0000 https://www.mustpower.com/?post_type=product&p=24134 Off Grid Inverter Charger 12V/24V | 10~30A | AC 120V EH2900 LV series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.]]> ■ Sine wave inverter
■ Adjustable charging current from utility
■ Adjustable battery charging current
■ 3 steps charging algorithm
■ Friendly user interface
■ Multi-function display
■ Overload and short-circuit protection
■ Battery reverse polarity protection
■ Deep discharge protection
■ Automatic voltage regulationCommunication with PC

MODEL EH29-0312 LV EH29-0412 LV EH29-0512 LV EH29-0612 LV EH29-0812 LV EH29-1012 LV EH29-0624 LV EH29-0824 LV EH29-1024 LV
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
Surge Rating 900VA 1200VA 1500VA 1800VA 2400VA 3000VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 110 or 120VAC Line mode: 95~125VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time 8ms(typical) 12ms(max)
AC INPUT
Voltage 110/120VAC
Selectable Voltage Range 70~140VAC ±5%
Low battery voltage alarm 70VAC ±5%
Low battery voltage recover 75VAC ±5%
High battery voltage alarm 140VAC ±5%
High battery voltage recover 135VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum start voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage cutoff 10-12.0VDC 20.0-24.0VDC
High battery voltage alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
10A 10A 15A 20A 25A 30A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection >110%~125% Load fault after 60s; >125%~150% Load fault after 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 15A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 15A
Maximum Bypass Current 15A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 300.5*319*132.2
Package Dimension (W*H*D)(mm) 391*187*325
N.W(kg) /
G.W(kg) /
GENERAL
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°Cstarting, <30°C Closing
Communication USB
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011);CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011) IEC60950-1:2005A+1:2009+A2:2013; EN IEC62040-1:2019
]]>
